High-Efficiency Heat Exchange: Dual-side enhanced heat exchange tube design improves heat transfer efficiency and reduces energy consumption by 15-20%
Multi-Voltage Adaptation: Supports 220V/380V dual voltage, flexibly adapting to global power grids
Durable Materials: Copper tube aluminum alloy/stainless steel materials are corrosion-resistant, anti-scaling, and extend service life
Smart Maintenance: Compact structure facilitates cleaning of heat exchange tubes and reduces downtime
Wide Temperature Range: Suitable for low-temperature environments of 8-18°C, meeting refrigeration and freezing needs
Environmental Design: Uses environmentally friendly refrigerants, complying with international environmental standards
Remote Monitoring: Supports intelligent monitoring systems for real-time equipment operation status monitoring
Fkv Series Air Cooling Conder | External Motor | Joint Pipe Size | |||||||||
Model | Cooling Capacity (KW) | Heat Exchange Area(m²) | Length (L)mm | Width (B)mm | Height (H)mm | Qty | Diameter | Power | Air Volume | Inlet Pipe | Outlet Pipe |
FNV-90 | 26.4 | 90 | 1465 | 855 | 900 | 2 | Φ450 | 2*250 | 2*5050 | Φ28 | Φ19 |
FNV-100 | 33.1 | 100 | 1465 | 855 | 900 | 2 | Φ450 | 2*250 | 2*5050 | Φ28 | Φ19 |
FNV-120 | 39.6 | 120 | 1755 | 1025 | 1080 | 2 | Φ550 | 2*550 | 2*7500 | Φ28 | Φ19 |
FNV-140 | 42.9 | 140 | 1755 | 1025 | 1080 | 2 | Φ550 | 2*550 | 2*7500 | Φ28 | Φ19 |
FNV-160 | 52.8 | 160 | 1755 | 1025 | 1080 | 2 | Φ550 | 2*550 | 2*7500 | Φ28 | Φ19 |
FNV-190 | 59.4 | 190 | 2190 | 1025 | 1080 | 2 | Φ600 | 2*800 | 2*9500 | Φ28 | Φ19 |
FNV-220 | 66 | 220 | 2190 | 1025 | 1080 | 2 | Φ600 | 2*800 | 2*9500 | Φ28 | Φ19 |
FNV-240 | 72.6 | 240 | 2450 | 1025 | 1080 | 3 | Φ550 | 3*550 | 3*7500 | Φ32 | Φ19 |
FNV-260 | 79.2 | 260 | 2450 | 1025 | 1080 | 3 | Φ550 | 3*550 | 3*7500 | Φ32 | Φ19* |
Commercial Refrigeration Systems:
Cold Storage: Stable operation in -18°C to -25°C low-temperature environments, ensuring food freshness
Freezer: -40°C ultra-low temperature environment, suitable for frozen food storage
Cold Chain Logistics: Maintaining 2-8°C constant temperature transportation, ensuring product quality of medicines and fresh produce
Food Processing Industry:
Food Processing Plants: Meets HACCP hygiene standards, preventing cross-contamination
Beverage Production: Ensures stable product taste and quality
Dairy Processing: Maintains 4°C constant temperature environment, ensuring dairy product quality
Pharmaceutical Cold Chain:
Pharmaceutical Warehouses: 2-8°C temperature control ensures drug quality
Vaccine Storage: -20°C ultra-low temperature environment ensures vaccine effectiveness
Medical Equipment: Provides stable refrigeration environment for medical equipment
Industrial Refrigeration:
Chemical Industry: Corrosion-resistant design adapts to chemical environments
Electronics Manufacturing: Precise temperature control ensures electronic component quality
Machinery Processing: Provides constant temperature environment for precision equipment
Air Conditioning Systems:
Commercial Air Conditioning: Improves heat exchange efficiency and reduces operating costs
Industrial Air Conditioning: Adapts to high-intensity operating environments
Special Air Conditioning: Provides refrigeration solutions for special environments
Installation Steps:
Site Preparation:
Confirm stable installation location and level ground
Reserve at least 50cm ventilation space for good heat dissipation
Check power supply and confirm voltage match (220V/380V)
Equipment Installation:
Connect pipelines according to instructions, ensuring proper sealing
Install fixing brackets to prevent equipment vibration
Connect power lines, paying attention to grounding protection
Pre-Startup Inspection:
Check pipeline connections for tightness
Confirm correct refrigerant charge
Check fan operation
Startup and Operation:
Gradually turn on power and observe equipment operation status
Check pressure gauge readings for normalcy
Monitor temperature changes to ensure reaching set values
Daily Maintenance:
Clean heat exchange tube surfaces monthly to remove dust and dirt
Check refrigerant charge quarterly
Inspect pipeline connections semi-annually to prevent leaks
Conduct annual comprehensive maintenance and replace wearing parts
Special Operation Points for FNV190 Model:
Confirm voltage stability within rated range before startup
Maintain condenser ventilation and cleanliness to avoid blockages
Regularly clean filters to prevent dust accumulation
Pay attention to moisture and dust protection during use to extend equipment life
Check fans and pipelines during maintenance to avoid blockages
Q1: Does the FNV Condenser support customization?
A: Yes, we offer comprehensive OEM customization services including:
Adjusting refrigerant types (R22, R404A, R134a, etc.)
Customizing dimensions and interfaces
Optimizing heat exchange parameters
Providing dedicated control systems
Brand logo customization
Q2: What is the maintenance cycle?
A: Recommended maintenance cycle:
Daily inspection: Check before starting up each day
Monthly maintenance: Clean heat exchange tubes monthly
Quarterly maintenance: Comprehensive inspection quarterly
Annual maintenance: Replace wearing parts and conduct comprehensive maintenance annually
Q3: What if the voltage doesn’t match?
A: We offer multiple solutions:
Transformer adaptation services
Multi-voltage version options
Custom voltage conversion equipment
Global voltage compatibility design
Q4: Which refrigerants is the FNV Condenser suitable for?
A: Supports various refrigerants:
R22: Traditional refrigerant, suitable for old systems
R404A: Environmentally friendly refrigerant, suitable for new systems
R134a: Environmentally friendly refrigerant, suitable for food and pharmaceutical industries
Other special refrigerants can be customized according to requirements
Q5: What is the equipment warranty period?
A: Standard warranty period is 2 years, including:
Material defect warranty
Manufacturing process issues
Performance guarantee under normal use
Q6: How to choose the appropriate model?
A: When selecting a model, consider:
Cooling capacity requirements
Application scenarios
Temperature requirements
Voltage conditions
Space limitations
Our technical team can provide professional model selection advice.
